IBIS
HD6 XTR Di2
HD6 XTR Di2
Normaler Preis
€12.549,99 EUR
Normaler Preis
Verkaufspreis
€12.549,99 EUR
Stückpreis
/
pro
inkl. MwSt.
Versand wird beim Checkout berechnet
Verfügbarkeit für Abholungen konnte nicht geladen werden
| Version | HD6 |
| Frame Material | Carbon front and rear triangle |
| Frame Weight | A size large HD6 frame with an X2 weighs 7.7 lbs / 3.5kg |
| Wheel Size | 29/27.5” mixed wheelsize, up to 2.5" tire clearance |
| Front Travel | 180mm |
| Rear Travel | 165mm |
| Shock Specs | 230 x 65mm |
| Shock Eyelet Hardware | 25mm x 8mm front / 15mm x 8mm rear |
| Boost Axles | 148mm rear / 110mm front |
| Seatpost Diameter | 34.9mm |
| Rear Brake | 180mm Post mount / 220mm max rotor |
| Chainstay Length | 435mm |
| Bottom Bracket | Threaded (73mm BSA) |
| Chainline | 55mm chainline |
| Chainring | 30T - 34T |
| Derailleur Hanger | SRAM UDH |
| ISCG 05 Compatible | ISCG 05 Tab Mount available separately |
| Headset | ZS44 upper / ZS56 lower |
| Colors | Traffic Cone Orange, Enchanted Forest Green or Lavender Haze |
| Sizes | SM (1) /MD (2) /XM (3) /LG (4) /XL (5) |
| Frame Warranty | Lifetime |
