| FRAME |
Aluminum, 170mm Travel, Ride Aligned™ |
| FORK |
RockShox Zeb RC 180mm, DebonAir, 44mm Offset, 1.8 Taper, E-Rated |
| REAR SHOCK |
RockShox Super Deluxe Coil, Select+, Custom Tune, 230x62.5mm, 400lb/in (S), 450lb/in (M), 500lb/in (L), 550lb/in (XL) |
| REAR SHIFTER |
Shimano Deore SL-M6100-R |
| REAR DERAILLEUR |
Shimano SLX RD M6100 |
| CRANKSET |
Shimano FC-EM600, 34T, 165mm |
| CASSETTE |
Shimano Deore CS-M6100-12, 10-51T, 12 Speed |
| CHAIN |
Shimano Deore CN-M6100 |
| FRONT BRAKE |
Shimano BR MT420, 4 piston, Metallic Pads |
| FRONT BRAKE ROTOR |
Shimano RT-64, 203mm |
| REAR BRAKE |
Shimano BR MT420, 4 piston, Metallic Pads |
| REAR BRAKE ROTOR |
Shimano RT-EM600 203mm, Integrated Sensor Magnet |
| BRAKE LEVERS |
Shimano BR MT420 |
| HANDLEBAR |
Butted 6061 Alloy, 800mm, 25mm Rise |
| STEM |
Alloy, 40mm Length, 35mm Clamp |
| SEATPOST |
TranzX YS105 Adjustable Dropper, 34.9mm, 125mm (S), 150mm (M), 170mm (L), 200mm (XL) |
| DROPPER LEVER |
Norco Dropper Lever |
| HEADSET |
FSA No.55R-1 Sealed Bearing |
| SADDLE |
WTB Volt 250 Sport |
| GRIPS |
SDG Thrice Lock-On, Thin (S, M), Thick (L, XL) |
| FRONT HUB |
Shimano HB-MT410, 15x110mm Boost, Center Lock |
| REAR HUB |
Shimano FH-MT510, 12x148mm Boost, Micro Spline, Center Lock |
| RIMS |
Stan's Flow D, 32H, 29" |
| FRONT TIRE |
Maxxis Assegai 2.5" 3C MaxxGrip/DD/TR/WT |
| REAR TIRE |
Maxxis Assegai 2.5" 3C MaxxGrip/DD/TR/WT |
| SPOKES/NIPPLES |
Stainless Black |
| VALVES |
Tubeless Presta |
| SEALANT |
Stan's - 200ml |
| MOTOR |
Shimano STEPS EP8 |
| BATTERY |
Sold Separately. Removable. 900Wh, 720Wh and 540Wh Options. |
|
