| FRAME |
Carbon Front Triangle and Seatstay, Aluminum Chainstay, 170mm Travel, Ride Aligned™ |
| FORK |
Fox Factory FLOAT 38, GRIP 2, HSC/LSC, HSR/LSR, 180mm, 44mm Offset, E-Rated |
| REAR SHOCK |
Fox Factory DHX2, Coil Spring, HSC/LSC, HSR/LSR, Custom Tune, 230x62.5mm, 400lb/in (S), 450lb/in (M), 500lb/in (L), 550lb/in (XL) |
| REAR SHIFTER |
Shimano XT Sl-M8100 I-Spec EV |
| REAR DERAILLEUR |
Shimano XTR M9100 |
| CRANKSET |
Shimano FC-M8150 E-MTB, 34T, 165mm |
| CASSETTE |
Shimano SLX CS-M8700, 10-51T, 12 Speed |
| CHAIN |
Shimano SLX CN-M7100 |
| FRONT BRAKE |
Shimano XT BR-M8120, 4 Piston Metallic Pads, Ice Tech |
| FRONT BRAKE ROTOR |
Shimano SM-RT MT800, 203mm, Ice Tech |
| REAR BRAKE |
Shimano XT BR-M8120, 4 Piston Metallic Pads, Ice Tech |
| REAR BRAKE ROTOR |
Shimano RT-EM810 XT, 203mm,, Ice Tech, Integrated Sensor Magnet |
| HANDLEBAR |
Deity Ridgeline, 800mm, 25mm Rise |
| STEM |
CNC Alloy, 40mm Length, 35mm Clamp |
| SEATPOST |
OneUp Adjustable Dropper, 34.9mm, 120mm (S), 150mm (M), 170mm (L), 210mm (XL) |
| DROPPER LEVER |
OneUp Lever 1x |
| HEADSET |
FSA No.55R-1, Sealed Bearing |
| SADDLE |
Ergon SM-10 E-Mountain Sport |
| GRIPS |
DMR DeathGrip A20 Soft, Thin (S, M), Thick (L, XL) |
| FRONT HUB |
DT Swiss 350H, 15x110mm Boost, Center Lock |
| REAR HUB |
DT Swiss 350H, 12x148mm Boost, Micro Spline, Center Lock |
| RIMS |
DT Swiss E 1700 Hybrid E-Rated Wheelset, 29" |
| FRONT TIRE |
Maxxis Assegai 2.5" 3C MaxxGrip/DD/TR/WT |
| REAR TIRE |
Maxxis Assegai 2.5" 3C MaxxGrip/DD/TR/WT |
| SPOKES/NIPPLES |
DT Swiss Stainless |
| VALVES |
DT Swiss Tubeless Presta |
| SEALANT |
Stan's - 200ml |
| MOTOR |
Shimano STEPS EP8 |
| BATTERY |
Integrated, Removable, Sold Separately, 900Wh, 720Wh and 540Wh Options |
|
